Fuel Transfer TPU Lay Flat Hose



Fuel transfer hose is designed to transfer liquids such as oil, fuel, chemicals and waste water. Antistatic materials are added into the PU raw materials, and several pcs of cooper wires are attached into the reinforcement layer and reach the coupling to provide antistatic properties. It is widely used in temporary oil transfer, army and ship fuel supply.

Fuel Transfer TPU Lay Flat Hose

Description：

  TPU Fuel Transfer Hose is a super heavy-duty through-the-weave polyurethane (PU) covered hose.  The jacket inside the hose shall be made from high tensile synthetic polyester filament yarn,with circular woven method, it will totally be embedded in the PU compound, the covered PU will protect it against mechanical damage, forming a single homogeneous construction without any glues or adhesives of any type between them.Thermoplastic polyurethane (TPU) is extruded “through the weave” in a unique one step production process. This process combined with UV protection additives and ageing-resistant in the compounds makes this transfer hose ideally suited for high abrasion applications in the mining and water transfer/fracking applications.Construction
Construction
Cover and liner: High quality TPU
Reinforcement: High tenacity synthetic yarn(With copper wires available inside to be anti-static)
Technical Parameters
Color: green or as required
Size: 2 inch-8 inch
Length: 200m(660ft) or as required
Temperature: -50°C～+80°C(-60°F to 176°F )
Features
Antistatic, high pressure, oil and chemicals resistance, UV resistance, safe and easy Iinstallation, long service time
Application
Temporary oil and fuel transfer, army and ship fuel(oil) supply, hydraulic fracturing
Specifition：

Size Working Pressure Burst Pressure Wall Thickness Length
Inch mm Bar Psi Bar Psi mm m/ft
2 51+1.5 17 250 51 750 2.7 200/660
3 77+2.0 17 250 51 750 3
4 103+2.0 17 250 51 750 3.2
6 154+2.5 17 250 51 750 4.2
8 204+3.0 15 215 45 645 4.5

Size, working pressure and wall thickness can be customized as required.
